Purpose
고정 진동 진단 시스템에서 진동 속도 측정.
Features
The built-in electronic amplifier-transducer converts the piezoelement signal to a low-resistance voltage signal proportional to vibration velocity.
Electric insulation of piezoelement and built-in amplifier-transducer from the body eliminates the influence of grounding loop currents on measurement results.
Robust design, waterproof casing and non-detachable armored cable.
Stable characteristics and reliable operation.
